SP9100 Switch Pro Panel Power System

Take full control of your vehicle’s electrical accessories with the most advanced, compact, and reliable switch panel system on the market.
Engineered for off-road, overlanding, marine, powersports, and performance applications, the SP9100 delivers clean wiring, simplified installation, and rock-solid power management—all in a rugged, waterproof package built in the USA.

What’s Included

Switch Panel & Power Module
RCR-Touch®8 Cover – Snaps on for confident switch selection while wearing gloves or traveling rough terrain
(U.S. Design Patent No. US D922,969 S)
11 ft Communication Cable between switch panel and power module
Power Cable with 125A Inline Fuse
125 User-Selectable Legends (horizontal orientation)
Installation Brackets & Hardware
16-pin Color-Coded Output Harness
Detailed Installation Guide

Key Features

RGB Backlighting for fully adjustable switch illumination
Built-In Bluetooth® Module – Pair with the free Switch-Pros App
Mobile Control – Program and operate switches from any iOS or Android device
Battery Voltage Readout via the app
Orange LED Switch Indicators for clear visual feedback
LED Input Status Indicators on the power module for simplified troubleshooting
IP67 Waterproof Rating – Designed for harsh environments
Made in the USA

Specifications

125A Total System Capacity with 8 configurable outputs
4 outputs rated at 35A
4 outputs rated at 20A
Adjustable Overcurrent Protection
Switch Panel Size: 4” L × 2” W × 0.375” H
Power Module Size: 6” L × 3” W × 0.5” H (excluding connectors)
Operating Temperature: −40°C to 125°C (Power Module)
Waterproof Rating: IP67 (Panel & Module)

Programming & Advanced Functions

The SP9100’s intelligent control system provides unmatched flexibility:

Preset Dimming with Memory (100% → 10%)
Master Mode – Control up to 7 outputs with a single touch
On/Off or Momentary Modes
Ignition- or Battery-Triggered Inputs
Flash/Strobe Modes with multiple user-selectable patterns
One-Touch Strobe Activation
Automatic Power-Up with vehicle start
Timed Off-Delay Function
Low Voltage Disconnect for battery protection
Sleep Mode for minimal power draw
Two External Trigger Inputs – Each can activate up to four outputs (Active High or Low)
Daisy-Chain up to 3 Switch Panels to a single power module
No bulky relay box needed—streamlines your wiring and installation

Why Choose the SP9100

Whether outfitting a trail rig, work truck, SxS, race vehicle, or custom build, the SP9100 provides professional-grade power distribution and modern app-based control in a compact, durable system. Its proven reliability and flexible programming make it one of the most trusted switch solutions in the industry.
